Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Westinpower
  • Model Number: TP550L
  • Output Type: AC Three Phase
  • Speed: 1500RPM
  • Frequency: 50Hz
  • Rated Power: 500KVA/400KW
  • Rated Voltage: 230/400V
  • Rated Current: max. 794A
  • Packaging Detail: STANDARD EXPORT PACKAGE
  • Delivery Detail: 15DAYS
  • Engine: By Perkins 2506A-E15TAG2
  • Alternator: Leroy Somer LSA47.2 M7
  • Controller: DSE7320
  • Breaker: ABB
  • Factory Certificate: ISO8528, ISO9001, ISO14001
  • Product Warranty: One Year/1000 Hours

Packaging & Delivery

Packaging Details Packing under shrunk plastic film or wooden pack
Delivery Time 30 days after T/T 30% deposit received


Standard features

Open Type



- Engine : 2506A-E15TAG2

- Charge alternator : 24V

- Governor : ECM

- Generator :  LEROY SOMER, LSA47.2 M7

- Single bearing alternator IP 23

- Insulation class H/H

- Radiator 50°C max with coolant cap

- Skid and vibration isolators

- Dry type air filter

- Main line circuit breaker

- Industrial muffler

- 24V battery and cable

- User’s manual

Silent Type

Weight and Dimensions

GEN-Set

Dimension ( L×W×H )

Weight

Open Type

3420mm×1150mm×1990mm

3741Kg

Silent Type

5206mm×1506mm×2586mm

4991Kg

Generator Ratings

Voltage

Hz

Phase

Power factor

Standby AMP

Standby Rating

(KVA/KW)

Prime Rating

(KVA/KW)

400/230V

50

3

0.8

794A

550KVA / 440KW

500KVA /400KW

Engine Data

Manufacturer/Model

WITH PERKINS   2506A-E15TAG2  4-cycle

Cylinder /Arrangement

6 / L

Displacement

15.2 L

Bore and Stroke

137 mm × 171 mm

Compression ratio

16 :1

Rated RPM

1500 RPM

Max. stand by power at rated RPM

495KW

Frequency regulation , steady state

± 0.25%

Governor : type

ECM

Exhaust System

Exhaust gas flow

98 m3/min

Exhaust temperature

550°C

Max back pressure

6.8kPa

Fuel System

Fuel consumption100% (of the Prime Power)

100.0 L/h

Oil system

Total oil capacity w/filters

62.0 L

Air intake

Engine air flow

36.6 m³/min

Coolant System

Radiator & engine capacity

58.0 L

Max water temperature

107°C

Thermostat

88-98°C

Alternator Data

Manufacturer / Type

LEROY SOMER / LSA47.2 M7

Number of phase power

3

Factor (Cos Phi)

0.8

Pole : number

4

Bearing : number

1

Coupling

Direct

Exciter type

Brushless SHUNT

lnsulation : class , temperature rise

H / H

protection

IP23

  Control panel

The DSE7320 is made by DEEPSEA in England and is a new control module for single gen-set applications, and it is an Automatic Start Control Module and is simple to operate,and the module includes USB,RS232 and RS485 for expansion device connectivity.

Specifications: Frequency meter, Ammeter, Voltmeter

Alarms and faults Oil pressure, water temperature, No start-up, Over speed, Min/max alternator, Min/max battery voltage, Low fuel level, Emergency stop. Connect to VOLVO J1939.

Engine parameters: Hours counter, Oil pressure,Water, temperature, Engine speed, Battery voltage, Fuel level.

Optional parts:

Silent canopy / silent container, ATS, synchronization system, external fuel tank, water separator, jacket heater, battery charger, etc. If needed please contact us for more details.

Default packaging:  Packing under shrunk plastic film

Default shipping: Container loading, available loading quantity depends on genset models and sizes (please contact us for detail solutions)

Delivery Term: FOB SHANTOU

Payment Term: T/T or L/C at sight

Warranty for gensets:  One year or 1000 hours (whichever comes first) from date of initial startup,and not exceeding 18 months after shipment by WESTINPOWER CO.,LTD.
